| Instructions for use： |
|
| Way of working： | S1 |
| Insulation class： | B F |
| Ambient temperature： | -30℃-60℃ |
| Scope of application： | 4D-315 380V/50Hz 0~90Pa (20Pa-1350m3/h) |
| 4E-315 220V/50Hz 0～90Pa(20Pa-1350m3/h) | |
| 6D-315 380V/50Hz 0~50Pa(20Pa-720m3/h) | |
| 6E-315380V/50Hz O~50Pa(20Pa-740m3/h) |
| Listed Model | Voltage | Frequency | Current | Input | Speed | Air volume | Capacitance | Noise | Net weight | License | No.on the curce |
| （V） | （HZ） | (A) | （W） | (r/min) | (m³/h) | (μ F) | (dBA) | (kg) | |||
| YWF-4D-315 | 380 | 50 | 0.23 | 80 | 1300 | 1439 | / | 60 | 3.5 | ce ccc | ① |
| YWF-4E-315 | 220 | 50 | 0.45 | 85 | 1350 | 1537 | 4 | 60 | 3.5 | ce ccc | ② |
| YWF-6D-315 | 380 | 50 | 0.16 | 55 | 920 | 1049 | / | 58 | 3.5 | ce ccc | ③ |
| YWF-6E-315 | 220 | 50 | 0.28 | 60 | 920 | 1040 | 2 | 58 | 3.5 | ce ccc | ④ |
